| S.No. |
Room No. |
Name of the Lab |
Major Apparatus / Equipment / Machines |
Report |
| 1 |
P-101 |
AUTOMOTIVE ELECTRICAL LAB |
Battery Charger, Battery Load Tester , Working Bench , Autoelectrical Test Bench, Front Wheel Aligner, Tool Box, Socket Box Smole, Socket Box Big | |
| 2 |
P-BLOCK |
BOSH WORK SHOP |
Tyre Changer, Wheel Balancer, Air Conditioning Service , Nozzle Cleaner, Diesel Ful Pumpcali Bration, Working Bench , Air Comprassor , Hydrolic Lift | |
| 3 |
Q-006 |
AUTOMOBILE LAB |
Hydraulic Braking System , Diesul Fuel Injection System, Petrol Fuel Supply System, Battery Ignition System, Lubrication System, Cooling System, Engine Cut Section, Suspension System, Differential System Of Rear Axle, Steering System, 5 Spead Gear Box Synchromesh, Electrical And Lightning System, Automobile Spare Parts, Manual In Almirah, Gas Analizer Petrol, Jeep Chasis Actual Cut Model Section, Power Steering, Ic 4 Stroke Petrol Engine Test Rig, Cm Ierrzed Multi Vcr Engine | |
| 4 |
Q-103 |
MACHINE DESIGN LAB & CAD/CAM LAB |
Computer (hp Prodesk), Cnc Drill , Cnc Lathe, Cnc Turning Lathe Siemens 828 | |
| 5 |
Q-004 |
Thorey Of Machine Lab |
Cam Analysis Apparatus, Belt & Pulleys, Epicycylic Geartrain Apparatus, Governer Appratus, Motorizegy Gyroscopic, Slider Crank Mechanism, Universal Vibration Appratus, Whirling Of Shaft, Static & Dynamic Blancing Machine, Band And Block Brake, Disc Brake, Kinetic Pairs, Clutch Appratus, Gear Box, Governer Appratus, Quick Return Motion, Watts Mechanism, Four Bar Link Mechanism, Scotch Yoko Mechanism, Gyrascope, Pento Graph Mechanism, Reciprocating Engine Mechanism, Train Of Gear Wheels | |
| 6 |
Q-003 |
Material Science Testing Lab |
Universal Testing Machine, Hardness Testing Machine, Impact Testing Machine, Torsion Testing Macine, Plastic Moulding Machine, Fatigue Testing Machine, Heat Treatment Furnace, Polishing Machine | |
| 7 |
Q-005 |
Thermodynamics Lab |
Air Compressor, Water Tube Boiler, Battery Charger, Battery , Four Stroke Petrol Engine, Four Stroke Diesel Engine, Four Cylinder Engine Eight Valve, Four Stroke Petrol Engine Morse Test, Four Stroke Petrol Engine With Electric , Loading, Locomotive Boiler, Lancshire Boiler, Pure Reaction Turbine, Radial Turbine, Steam Engine Model, Steam Engine Model With Boiler, Two Stroke Petrol Engine, Two Stroke Diesel Engine, Two Stroke Petrol Engine Scooter, Compound Steam Engine | |
| 8 |
Q-005 |
Meausrement And Metrology Lab |
Vernier Caliper, Depth Micrometer, Vernier Depth Gauge, Vernier Caliper Dial Type, Combination Set, Bevel Protector, Precision Block Sprit Level, Dial Bore Gauge, Filler Gauge Set, Straight Edge, Out Side Micrometer, Out Side Micrometer, Radius Gauge, Radius Gauge, Meter Scale, Meter Scale, Vernier Height Gauge, Sine Bar, Thread Ring Gauge, Thread Plug Gauge, Vernier Tooth Gear, Tool Maker Microscope, Surface Plate Graphite, Slip Gauge Box, Tachometer, Stroboscope, Radius Gauge | |
| 9 |
Q-106 |
Refrigeration And Air-Conditioning Lab |
Refrigeration Test Rig, Air-conditioning Test Rig, Refrigeration Test Rig (computerized), Air-conditioning Test Rig (computerized), Window Ac Model | |
| 10 |
Q-107 |
HEAT & MASS Transfer Lab |
Heat Transfer Through Composite Wall, Double Pipe Heat Exchanger, Emissivity Measurement Apparatus, Heat Transfer Through Lagged Pipe, Heat Transfer In Natural Convection, Heat Transfer From A Pin Fin, Heat Pipe Demonstrator, Stefan Boltzman Apparatus | |
| 11 |
Q-106 |
Fluid Mechanics Lab |
Reynolds Apparatus, Impact Of Jet Apparatus, Open Orifice Apparatus, Bend Meter Apparatus, Friction Factor Apparatus, Venturimeter/orificemeter Apparatus, Pitot Tube Apparatus, Metacentric Height Apparatus, Boundary Layer Apparatus, Centrifugal Blower, Francis Turbine, Hydraulic Ram, Pelton Wheel Turbine, Impact Of Jet, Reciprocating Pump, Submersible Pump, Centrifugal Pump | |
| 12 |
Q-001 |
MANUFACTURING SCIENCE & TECHNOLOGY |
Bending Machine, Bench Vice, Drill Machine, Molding Machine, Spot Welding Machine, Lathe Machine, Wood Working Lathe, Radialdrill Machine, Bench Grinder, Are Welding, Tig Welding Set, Mig Welding Set, Gas Welding Set, Power Hack Saw , Open Hearth Furnace, Press Machine, Two Rolls Rolling Machine, Milling Machine, Shaper Machine, Chopsaw , Hand Grinder, Sapstan Lathe | |
| 13 |
Q- 303 |
I.O.P LAB - 2 (Ansys, SAP, IOT) |
Computer, Wheel 75 No. , Ldr,oled, Assembly Kit, Nx Cam, Computer, Nxcad 100, Femap, Trening (nx Cam,nx Cad Femap, Sap) | |
| 14 |
Q-205 |
I.O.P. LAB -1 (Solid Edge) |
Computer | |
| 15 |
Admin Block |
FESTO |
Computer , Work Station , Pnuematic Kit Trining, Plc Kit, Mps Station, Industry 4.0, Licences Pcs, Necessary Software | |
| 16 |
B4-208 |
ENGINEERING GRAPHICS LAB |
Drawing Board, Computer | |
| 17 |
P-BLOCK |
WORKHOP LAB 1ST YEAR |
Drill Vice, Glass Cutter, Lathe Machine, Bench Vice, Carpentry Vice, Pedestal Grinder, Pedestal Drill Machine, Arc Welding Machine, Furnace , Swage Block, Anvil, Steel Tape, Hand Blower, Surface Plate, Goti Spener Set, Outside Micrometer, Number Punch , Alphabetic Punch, Vernier Outside, Vernier Caliper Outside, Ghan, Iron Jack Plane | |
